Low-E coated glass(T Series)

Low-E coated glass is one of the coated glass products withvarious metal or other compound depositions on the surface.It has different transmittance to visible light and higherreflectance against far Infrared. We provide single silver,double silver Low-E coated glass and related Compoundglass products with optimized performance for customersaccording to the actual demands and requirements ofdifferent climate zones.

Characteristics:

1. Neutral color expands the unlimited creativity of architects.

2. Unprecedented combination of solar control and visible light transmittance.

3. Excellent spectrum selectivity performance, becomes the first choice of high-end green building.

4. Revolutionary energy efficient performance, greatly decrease the equipment costs of green buildings.

Applied area : tropical & sub-tropical areas

Applied building : public, commercial and residential buildings

Recommended application : green buildings


Performance parameters:

Product Configuration

Colour

Visible light

Sunlight

NFRC 2010

EN673

JGJ151

Tvis%

Rvis%

U-value(W/m2.K)

SC

SHGC

LSG

U-value(W/m2.K)

K-value(W/m2.K)

SC

Out

In

Tsol%

Rsol%

Air

Argon

Air

Argon

Air

Argon

Winter

Summer

Winter

Summer

6UT72+12A+6UC

Grey

70

16

16

27

56

1.66

1.60

1.38

1.29

0.33

0.29

2.40

1.60

1.27

1.63

1.35

0.37

6UT72+16A+6UC

Grey

70

16

16

27

56

1.70

1.34

1.44

1.08

0.33

0.29

2.40

1.35

1.14

1.66

1.41

0.36

6T70+12A+6C

Grey

68

14

15

26

37

1.65

1.60

1.38

1.28

0.35

0.30

2.30

1.59

1.26

1.61

1.32

0.38

6T70+16A+6C

Grey

68

14

15

26

37

1.70

1.34

1.44

1.07

0.34

0.30

2.30

1.35

1.13

1.62

1.37

0.38

Notes:

  1. This data is only for the central area of the glass, calculated by the "Window 7.1" software in accordance with the American NFRC standards and JGJ151-2008 standards.

  2. The product data is for reference only, and the final product parameters shall be subject to those provided by Jinjing for specific projects.

  3. The formula for the light-to-heat ratio is the ratio of visible light transmittance to solar heat gain coefficient.

  4. The argon gas in the structure is 10% air + 90% argon gas.
